Add more inputs and outputs to your interface

Expand your studio connectivity by adding more inputs and outputs to your ADAT-compatible interface with the Revolution EXP! You get 16 analog TRS connections (8-in, 8-out), as well as 16 channels of ADAT I/O. Boutique component selection and proprietary Macro MMC clocking ensure that the Revolution EXP makes every device you connect sound its absolute best.

Grow your studio

Expanded I/O will let you take your production workflow to exciting new places. Add hardware compressors, stereo reverbs, or any other external hardware processor to your DAW workflow. Capture multi-channel recordings of your hardware synths and drum machines. Connect your preamps to the eight inputs to record multi-channel drums. Use the eight outputs to connect your Revolution EXP to an analog summing mixer; use two inputs for your stereo return. You can even use those eight outputs to connect a multi-speaker array and mix in Dolby Atmos!

Features:

• Add more I/O to your ADAT-compatible interface
• 16 channels of pro-quality AD/DA conversion of up to 24-bit/192kHz
• Ultra-low jitter Macro MMC word clocking for supreme sync and maximum clarity; also accepts word clock in
• 16 analog TRS connections (8-in, 8-out) with -10 dB pads on Inputs
• 16 ADAT digital connections (8-in, 8-out)
• Boutique components from Nichicon, Vishay and Wima ensure maximum signal quality and low noise
• Supports 44.1, 48, 88.2, 96, 176.4, 192 kHz sample rates
• External power supply
