From TELEFUNKEN Elektroakustik

Prior to 1959, TELEFUNKEN GmbH distributed Neumann GmbH microphones throughout the world. When Neumann GmbH decided to take their distribution direct, TELEFUNKEN GmbH commissioned Austrian company AKG Acoustics GmbH to produce a series of 5 microphones. This series of microphones was comprised of the famous ELA M 251, the ELA M 250, the stereo ELA M 270, and two small capsule microphones, the ELA M 260 and the ELA M 261.

TELEFUNKEN Elektroakustik is pleased to offer the ELA M 260, our first small diaphragm tube condenser. While not a historically accurate reproduction of the original ELA M 260 like the "Diamond Series" microphones, our version of the ELA M 260 is definitely built with the same attention to detail and level of quality as its Diamond Series brethren.

Arguably one of the best recording tools for acoustic and classical music, the ELA M 260 system features a new circuit design based around a TELEFUNKEN EF-732 vacuum tube and a custom output transformer that is wound to exacting specification in the United States. The combination of these features yields a microphone that is unlike any other small diaphragm microphone that you have ever experienced.

All ELA M 260 system packages are supplied with a set of three interchangeable capsules (the 260 cardioid, 261 omni, and 262 hyper-cardioid), and include elastic shockmounts, wooden microphone boxes and a dedicated power supply.

In use, the ELA M 260 has plenty of tone with excellent detail and clarity. It captures sources with a natural presence, making it a fantastic tool for recording acoustic instruments of all types. Violin, cello, upright bass, drum overheads, percussion, woodwinds, saxophones, strings, and especially acoustic guitar all sound amazing through the ELA M 260. Also, don't discount this for vocals just because it's small. Its unique tonal character is very well suited for a myriad of applications, both traditional and not.

All system packages of the ELA M 260 can have a custom adaptor added which was designed by our friend and fellow audio enthusiast Chip Machokas that permits the use of any of the AKG "CK" series of capsules (or capsules made by other manufacturers with the same thread) AND Neumann bayonet-style capsules.

Type

Condenser Pressure Gradient

Capsule

M260, M261, M262 Gold sputtered 3-micron

Frequency Range

20Hz / 20kHz

Polar Pattern

Cardioid, Omindirectional, Hypercardioid

Sensitivity

14MV/Pa = -37dB (0dB = 1v/Pa) -10bD

Impedance

200 ohms

SPL

120 dB

Non Linear Distortion

(for 1% THD @ 1KHz) 120dB

Equivalent Noise

19dB (A-weighted)

Tube Type

Telefunken EF-732

Power

Dedicated Power Supply

Weight

4.2 oz (119g)

Size

5 1/2" (140mm) length x 13/16" (21mm) diameter

Extras

NG Style Power Supply, Shock Mount, Mic Clip, Wooden Box

Free 3-Year Warranty

Sound Pure stands behind our products. Free three-year warranty on this item. Coverage exclusions live in Terms & Conditions, Section 27.

Level of support and expertise that simply isn't available at big-box megastores. Read the warranty →

Returns

This item is not eligible for the Try-Before-You-Buy 48-hour audition. Standard return policy applies — see Terms & Conditions, Section 18 for details.

Sound Pure Studios Control Room A — Durham, NC

Sound Pure Studios · Durham, NC

Come hear it in our control rooms.

Sound Pure is a working studio in Durham, NC — a 1,000 sq ft live room and two pro control rooms. Book a session to audition gear in a world-class acoustic space before you buy.

$1,695
